CONDUR ISR Watertight junction box without seals
KOUVIDIS launched COUNDUR junction boxes in 1992 in order to replace the metal ones. Since then, the company has proceeded to many upgrades to improve their functionality, ergonomics and mechanical strength. CONDUR junction boxes have gained the trust of the electrical installer and have been used in thousands of construction projects due to their high quality and reliability. They are a part of CONDUR – CONFLEX, MEDISOL – MEDIFLEX, SILCOR – SIFLEX, CONDUR HF – CONFLEX HF , MEDISOL PLUS–
MEDIFLEX PLUS conduit systems for cable management and protection.
APPLICATION FIELD
Ideal for exposed electrical installations.
- APPLICATION STANDARD:ΕΝ 60670-22
- INSTRUCTIONS FOR COMPLIANCE:2014/35/EE (LVD), 2011/65/EE (RoHS)
- COLOR:RAL 7035 Light grey
- TIGHTNESS DEGREES:min IP 65
Product Conformity to all requirements of relative European Directives.- Min-max permanent application temperature
- Ingrees protection against solid objects and water (EN 60529)
- Product with extra UV stability
- Non flame propagating product
- Product is made of halogen free raw materials
- Antistatic Technology IAS (Patent Protected 1009810)
- Antiscratch Technology ISR (Patent Protected 1010513)
- PROPERTIES
- CHARACTERISTICS
- PACKAGING
- DOWNLOADS
1The installer can open any hole of every diameter according to the installation requirements
2Watertight due to their elastic and directly mounted cover plate, providing Ingress Protection IP 65
3Flame retardant raw materials with 650oC thermal resistance (Glow wire test- IEC 60695-2)
4Each side of the boxes has provision for condensation when needed for the electrical installation
5The permissible operating circuits voltage inside the box can be up to 800V, allowing the use of three-phase circuits of normal operation 400VAC (±10% or ±15%) and DC circuits of photovoltaic or other applications
6No toxic or corrosive gases in case of fire
7Incorporates antistatic technology which protects against static electricity (Patent Protected: 1009810)
8Not attractive to rodents (European Patent EP2698792)
9Exceptional resistance to UV radiation
10Protection against scratching from cable routing (Patent Protected: 1010513)
| Properties | |
| Raw material | PC blend |
| Temperature range | -25oC to +60oC |
| Electrical characteristics | With electrical insulated characteristics |
| Resistance to flame propagating | Non flame propagating |
| Number of entries | – |
| Seals | – |
| Ingress protection | ΙΡ65 |
| Number of base knock outs | – |
| Conduit alignment | No |
| Condensation opening | Yes |
| Flame retardant | 650oC |
| Voltage | 800V |
| UV stability | Yes |
| Halogen free | No toxic or corrosive gases in case of fire |
| Rodent repellent | Not attractive to rodents |
| Antistatic technology | Protection against static electricity |
| Antiscratch Technology | Protection against scratching from cable routing |
| Type | Part number |  |
 |
 |
 |
 |
| Ø16 | 3022016 | 62 | 62 | 32 | 10 | 230 |
| Ø20 | 3022020 | 82 | 82 | 36 | 10 | 240 |
| Ø25 | 3022025 | 91 | 91 | 41 | 10 | 160 |
| Ø32 | 3022032 | 100 | 100 | 51 | 5 | 100 |
