Connection coupler For double wall pipes
Connection couplers with hooks have been designed in such a way that they can be safely connected with KOUVIDIS rigid and pliable double wall conduits, ensuring high ingress protection.
APPLICATION FIELD
Ideal for protection and management of buried underground power and telecommunication networks.
- APPLICATION STANDARD:EN 61386-24
- INSTRUCTIONS FOR COMPLIANCE:2014/35/EE (LVD), 2011/65/EE (RoHS)
- COLOR:RAL 9004 Black
- TIGHTNESS DEGREES:min IP 68
Product Conformity to all requirements of relative European Directives.- The product and its production process are inspected and approved by VDE German institute
- Min-max permanent application temperature
- Ingrees protection against solid objects and water (EN 60529)
- Product with extra UV stability
- Ingrees protection against solid objects and water (EN 60529)
- PROPERTIES
- CHARACTERISTICS
- PACKAGING
- DOWNLOADS
1Exceptional ageing resistance (UV stabilized)
2They carry three perimetric internal double hooks on each side
3they carry an inner lip for the proper conduits fixing and assembling
4Their design facilitates the introduction of the conduits (protruding entry lip) and maximises their retention (conical inner slope)
5Ensures Ingress Protection IP40 when connecting with GEOSUB conduits, IP44 when connecting with GEONFLEX conduits and IP68 when using KOUVIDIS adhesive and sealant
6It has been tested and certified by VDE German Institute
| Properties | |
| Raw material | Halogen free, heavy metals free (RoHS) and specially stabilized thermoplastic HDPE |
| Lower temperature range | -5oC |
| Upper temperature range | +90oC |
| IP ingress protection | IP 40 (coupler connected to GEOSUB conduit) IP 44 (coupler connected to GEONFLEX conduit) IP 68 (coupler bonded with KOUVIDIS sealant) |
| Resistance to flame propagating | Flame propagating |
| Ageing resistance | UV stabilized |
| Type | Part number |  |
 |
| Ø32 | 6101032 | 12 | 756 |
| Ø40 | 6101040 | 12 | 576 |
| Ø50 | 6101050 | 12 | 192 |
| Ø63 | 6101063 | 15 | 150 |
| Ø75 | 6101075 | 15 | 15 |
| Ø90 | 6101090 | 10 | 10 |
| Ø110 | 6101110 | 5 | 5 |
| Ø125 | 6101125 | 5 | 5 |
| Ø160 | 6101160 | 2 | 2 |
| Ø200 | 6101200 | 3 | 3 |
